PALO ALTO, Ca. – Stanford University researchers found that the best way to extend the life of a lithium-metal EV battery is to drain it and let it rest for a few hours.
The study, “Resting restores performance of discharged lithium-metal batteries,” published on February 7 in the journal Nature, found that this straightforward approach restored battery capacity and boosted overall performance.
Study co-lead author Wenbo Zhang, a Stanford PhD student in materials science and engineering, said:
We were looking for the easiest, cheapest, and fastest way to improve lithium metal cycling life.
We discovered that by resting the battery in the discharged state, lost capacity can be recovered and cycle life increased.
These improvements can be realized just by reprogramming the battery management software, with no additional cost or changes needed for equipment, materials, or production flow.
The study results could provide EV manufacturers with practical insights into adapting lithium metal technology to real-world driving conditions.
Lithium-metal vs. lithium-ion
Lithium-metal batteries could double the range of EVs, but they rapidly lose their capacity to store energy after just a few cycles of charging and discharging, rendering them useless for routine driving.
A conventional lithium-ion battery consists of two electrodes – a graphite anode and a lithium metal oxide cathode – separated by a liquid or solid electrolyte that shuttles lithium ions back and forth.
In a lithium-metal battery, the graphite anode is replaced with electroplated lithium metal, which enables it to store twice the energy of a lithium-ion battery in the same amount of space. The lithium-metal anode also weighs less than the graphite anode, which is essential for EVs. Lithium-metal batteries can hold at least a third more energy per pound than Li-ion batteries.
When a lithium-metal battery is discharged, micron-sized bits of lithium metal become isolated and trapped in the solid electrolyte interphase (SEI). This spongy matrix forms where the anode and electrolyte meet.
“The SEI matrix is essentially decomposed electrolyte,” Zhang explained. “It surrounds isolated pieces of lithium metal stripped from the anode and prevents them from participating in any electrochemical reactions. For that reason, we consider isolated lithium dead.”
Repeated charging and discharging results in the build-up of additional dead lithium, causing the battery to lose capacity rapidly. So, an EV with a lithium-metal battery would lose range much faster than a Li-ion-powered EV.
